LPMS-08 small slip ring

Product Introduction

LPMS Ultra Miniature Cap Conductive Slip Rings OD 5.5~6.5mm, length 11.8~13.5mm, 8-channel*1A, small form factor, high precision design, high and low temperature resistance, low contact resistance of the product, low torque, reliable operation. This series of slip rings are used for high precision instruments and equipment, suitable for the environment of harsh installation space.

Features:

Adoption of special groove design

Smooth rotation

Low electrical noise

Multiple contacts per circuit

Low contact pressure

Low contact wear

Main Applications:

Spruce

Robotics

Medical Equipment

Radar Antenna

CCTV security monitoring equipment
