Product Introduction

LPHF(LPCC) series RF rotary joint, also called high frequency slip ring, coaxial rotary joint, could support 1~6 channel RF/High Frequency transmitting when rotating 360°


Features:
◎Circuits No:up to 8 channels
◎Frequency: Single: 67GHz (Max)、Dual: 60GHz (channel 1)/18GHz (channel 2)
◎Supports mixed transmission of 1-200 power/signal channels
◎Low insertion loss and voltage standing wave ratio (VSWR)
◎Customizable high-frequency rotary joints with through holes available
Main Applications:
◎Radar antennas(Military)
◎Medical equipment
◎5G communication (RF antenna)
◎High-definition video surveillance
◎Electronic warfare/countermeasures system and related weapon system applications

Model

Model Code Frequency range Interface type Maximum peak power PDF 详情
LPHF-01 DC-18GHz SMA-F(50Ω) 1500W /
LPHF-02 DC-4.5GHz SMA-F(50Ω) 1000W /
LPHF-03 DC-2GHz SMA-F(50Ω) 1000W /
LPHF-04A DC-4GHz SMA-F(50Ω) 1000W /
LPCC-01A DC-3GHz Optional 1000W /
LPCC-02A DC-3GHz SMA-F(50Ω) 1000W /
LPC-1C1202 DC-3GHz Optional 1000W /
LPHF-06E 6 4GHz / /
LPHF-04E 4 4GHz / /
左右滑动

Full Support On Your Product

At JINPAT, we are dedicated to providing comprehensive support for your products. From the initial consultation and design phase to manufacturing, testing, and after-sales service, our expert team is here to ensure your slip ring solutions meet and exceed your expectations. We offer personalized guidance to help you select the right slip ring for your application, and our commitment to quality and customer satisfaction means you can rely on us for ongoing support and maintenance. Trust JINPAT to be your partner in achieving optimal performance and reliability for all your slip ring needs.
