Product Introduction

• LPA series large current slip ring is designed for big power transmitting, max current can support 7500A, with low contact resistance when 360°rotating.

•The housing of large current slip ring is designed with aluminum alloy or antiflaming engineering plastic, fast heat emission, and have a large number of cooling holes, Each slip ring would be tested for large current shock and temperature rise before delivery.

More than 500 high current slip ring solution drawings have been developed!

Features:
Voltage:Maximum7000V(Customization supported)
50A, 100A, 250A, 500A, 1500A and 3000A and other current specifications available
Supports signal and power transmission at the same time
Excellent waterproof performance, up to IP68, and meets indoor and outdoor working environments
Main Applications:
Oil Drilling Pipe
Construction machinery (cranes, excavators, fire trucks)
Wind power generation
Ship Podded Propeller
Floating cranes
Amusement series (dynamic 5D cinema)

Model

Model Code Current (A) Path number Voltage Rotational speed PDF 详情
LPA000-04350-01PE-03S 350A 4CKT 690V / /
LPA130-031000-01PE-50S 1000A 54 690VAC/220VAC/24VDC 2rpm /
LPA000-02120-01PE 120A 2 2000VAC 200rpm /
LPA000-02600-0440-12S 600A/40A 18 450V~750VDC/24V~32VDC 10rpm /
LPA000-03300-01PE-0350-0210-16S 300A/50A/10A 25 690VAC/380VAC/220VAC 10rpm /
LPA000-034000-01PE-0606-0203-72S-11L-01A 4000A/400A/8A/3A/250mA/0.3A 137 690VAC/340V/220VAC/30V/24V 3rpm /
LPA000-06405-06PE-03100-01PE-0616-02PE-0910-03PE 405A/100A/16A/10A 36 380VAC 20rpm /
LPA000-0780-0740-0915PE-0705PE-08S-FO12 80A/40A/15A/5A 51 3200VAC/240AC/24VDC 10rpm /
左右滑动
