Features
High Circuit Capacity:
Number of Circuits: 137CKT, offering extensive connectivity for various power and signal requirements.
Superior Electrical Specifications:
Insulation Resistance: ≥500MΩ@10000VDC(P) and ≥100MΩ@300VDC(S), ensuring excellent insulation properties.
Voltage: Handles multiple voltages, including 690VAC, 340V, 220VAC, 30V, and 24V, suitable for diverse marine applications.
Integrated Functionality:
Combines high and low current power rings, signal rings, and gas-liquid channels, providing a comprehensive solution for complex marine systems.
Advanced Shielding Design:
Features a best-in-class shielding design to minimize interference between weak electrical signals, such as temperature and position sensor signals.
Durability in Marine Environments:
Designed to withstand complicated marine corrosive environments, ensuring longevity and reliability.
Rigorous Testing and Standards Compliance:
Passed damp-heat tests compliant with IEC60068-2-30 standard and vibration tests compliant with IEC60068-2-6 standard, ensuring high reliability and durability under harsh conditions.
This slip ring is an ideal choice for ship podded propellers, providing a reliable and integrated solution to meet the demanding requirements of modern marine applications.
Electronic & Electric |
Mechanical |
| Circuits |
Total |
137CKT |
Working Speed |
0~3RPM |
| Detail |
3*4000A+1*400A+3*8A+2*3A+54*250MA+18*0.3A+38*signal+12*The standby |
A hole diameter |
/
|
Rating Voltage |
690VAC/340V/220VAC/30V/24V |
Contact Material |
High-end Copper Graphite
/Precious Metal
|
Dielectric Strength |
2500VAC@60Hz(P)
300VAC@60Hz(S) |
Housing |
Q235 Spray Coating(RAL 7032) |
Insulation Resistance |
≥500MΩ@1000VDC(P)
≥100MΩ@300VDC(S)
|
Installation |
Vertical Installation |
Environment |
Remarks |
Working Temperature |
-10°C~+50°C |
Application |
Ship Podded Propeller |
Working Humidity |
≥95%RH |
IP |
IP54 |
Other |
/ |
For more customized solutions, please feel free to contact us at any time
