VR Slip Ring

Features:
Compact structure and customizable size
Transmission HD signal, HDMI speed up to 4K@60Hz
USB3.0/USB2.0 and power signals can be integrated
Ultra-thin design, size can be customized
Transmit current and ordinary signals
Main Applications:
VR Slip Ring

Product Details

VR headsets (" eye masks ") are mainly divided into three types: glasses, helmets, and all-in-one machines.

The application of conductive slip ring is mainly concentrated in the motion sensing equipment, including: whole body motion recognition, mechanical exoskeleton input equipment, force feedback input equipment, gesture recognition, gesture recognition, eye recognition, etc., these devices generally use slip ring conductive ring, 360 degree slip ring, rotary electric joint


Electrical & Electronics

Mechanical
Circuits total

42CKT

Working speed 0~100rpm
Details

2*1.5A/1*DC/2*4A/1*HDMI/1*USB2.0

Contact material Gold to Gold
Operating voltage

46VAC/DC

Housing ilaterial Engineering plastics
Compressive strength

200VAC@50Hz(P)≥100VAC@50Hz(S)

Lead Wire Langth

Stotor:160±5mm  /125±5mm /75±5mm

Rotor:320±5mm /290±5mm /215±5mm

Insulation resistance

≥50MΩ@2000VDC(P)≥20MΩ@100VDC(S)

State resistance

 fluctuation signal

/
Enviromental

Others

Operating temperature

-20°C~+60°C

Application field VR Slip Ring
Working humidity

≤60%RH

Class of protection

IP54
