- Features:
- Gold-to-gold contact, stable transmission
- Very low contact resistance and stable fluctuation values (up to 1mΩ minimum, suitable for weak currents Sum signal）
- Main Applications:
- Companion robot slip ring
Please leave your message and we will contact you as soon as possible!
Robot slip ring technology has become a secret weapon to improve production efficiency by providing high-speed, continuous and stable production process,
accurately controlling production parameters, improving product quality, and realizing multi-process automation. With the continuous progress and application of technology,
we can expect that robot slip rings will play a more important role in automated production in the future.
Electrical & Electronics |
Mechanical |
|||
| Loop number | total | 6CKT |
Working speed | 0~250rpm |
| Details | 6/2A(2Mbpsa bove) |
Contact material | Gold to Gold | |
| Operating voltage | 0~240VAC/DC |
Housing ilaterial | Engineering plastics | |
| Compressive strength | ≥300VAC@50Hz |
Lead Wire Langth | Stotor:25±2mm |
|
| Insulation resistance | ≥200MΩ@300VD |
State resistance fluctuation signal |
≤30mΩ | |
Enviromental |
Others |
|||
| Operating temperature | -20°C~+80°C |
Application field | Companion robot slip ring | |
| Working humidity | ≤60%RH |
|||
| Class of protection | IP40 |
|||
