- Features:
- Compact structure, small product size
- Precious metal contact
- Conforms to UL certification, safe and reliable
- Main Applications:
- Circulating fan slip ring
When designing and manufacturing slip rings, it is necessary to fully consider its application scenarios and use conditions. For example, for high temperature,
low temperature or corrosive environments, you need to choose a material that is resistant to high temperature, low temperature or corrosion. For the application of high-speed rotation,
it is necessary to optimize the structural design of the slip ring to ensure its stability and reliability
| Electrical & Electronics |
Mechanical |
|||
| Loop number | total | 3CKT |
Working speed | 0~6rpm |
| Details | 3*3A | Contact material | Gold to Gold | |
| Operating voltage | 240V/DC | Housing ilaterial | Engineering plastics | |
| Compressive strength | 2000VAC@50Hz/1 second no breakdown (no rubber shell, only guide edge test) |
Lead Wire Langth | Stotor:200±5mm |
|
| Insulation resistance | ≥10MΩ@100VDC(P/S) |
State resistance fluctuation signal |
≤35mΩ | |
|
Enviromental |
Others |
|||
| Operating temperature | -20°C~+60°C | Application field | Circulating fan slip ring | |
| Working humidity | ≤60%RH |
|||
| Class of protection | IP40 | |||
