Product Introduction
JINPAT Electro‑Optical Rotary Joints combine fiber optic rotary joints (FORJs) with electrical slip ring channels to enable simultaneous transmission of optical signals, power, and control signals through a single rotating interface.
Features:
◎ Compact & Modular Design: Space-efficient layout allows easy integration into size-constrained systems
◎Industry-Specific Customization: Customized for diverse applications, including gimbals, medical imaging, HD surveillance, and remote operation systems
Main Applications:
◎ PTZ
◎ Medical imaging
◎HD surveillance
◎Remote operation systems

Product Details

Electro‑Optical Rotary Joints

JINPAT Electro‑Optical Rotary Joints combine fiber optic rotary joints (FORJs) with electrical slip ring channels to enable simultaneous transmission of optical signals, power, and control signals through a single rotating interface. Designed for compact integration and long-term durability, they deliver high-speed, interference-free performance in demanding environments. These hybrid systems are ideal for UAV gimbals, HD video systems, medical devices, and remote sensing platforms, with tailored solutions across more than 20 industries.


Customization & Services
          Tailor your slip ring with specific signal types, channel counts, protection levels, or mounting styles. 3D CAD models and technical support are available upon request.

Can’t find a suitable model? Contact us for 24/7 technical support .

For detailed product specifications , refer to product datasheets or contact our sales team.

Optimized for global markets – Precision-engineered for reliability in mission-critical applications.

Typical Models of Electro‑Optical Rotary Joints
Typical Model Fiber Channels Power Channels Supported Signal Types

Outer Diameter

   (mm)

Customization Options
No. of   Channels Insertion Loss No. of Circuits Voltage



LPC-D35-0315-2502-01E3-01FO




1






2dB




28


0-220V




USB 2.0 , Fast Ethernet , Gigabit Ethernet , HD-SDI , Common Signals


∅35



1.Customizable mechanical dimensions


2.Configurable power and signal channels


3.Full-frequency compatibility up to DC–67GHz RF


4.Integration with pneumatic and hydraulic rotary unions


5.Customizable IP protection level


6.Optional housing materials (aluminum alloy, stainless steel, etc.)


7.Mixed high-speed data transmission supported, including:

•USB 2.0

•Analog HD video (CVBS/CVI/AHD/TVI/XVI; PAL/NTSC/SECAM)

•Ethernet slip rings (Fast/Gigabit/Industrial Ethernet)

•Fieldbus slip rings (RS422, RS485, Profibus, Modbus, DeviceNet, CC-Link, CAN/CANbus, InterBus)

•Serial communication (I2C, BISS, SSI, SPI, UART, RS232, TTL, MIL-STD-1553B, IEEE 1394b)

•RTD signals

•Thermocouple signals

•Sensor signals

•Encoder signals




LPC-D60-2005-30S-01FO


20


0-220V


USB 2.0 , Fast Ethernet , Gigabit Ethernet , HD-SDI , Common Signals


∅60



LPT000-0210-02FO













2-7













4dB





2



0-380V



Fast Ethernet , Gigabit Ethernet , Common Signals



∅112





LPT000-0320-03FO




3




0-380V




Fast Ethernet , Gigabit Ethernet , Common Signals








∅190



LPT000-0415-12S-02E3-04FO


4


0-380V


Fast Ethernet , Gigabit Ethernet , Common Signals


∅108



LPT000-0305-05FO


3


0-380V


Fast Ethernet , Gigabit Ethernet , C

ommon Signals


∅148



LPT000-0640-0210-06FO


6


0-380V


Fast Ethernet , Gigabit Ethernet , Common Signals


∅190


LPT000-1210-39S-01E3-12FO


8-18


5dB


12


0-380V


Fast Ethernet , Gigabit Ethernet , Common Signals


∅140


LPA000-12400-0454-0827-0423-0813-04S-32FO


18-35


5dB


32


/


Fast Ethernet , Gigabit Ethernet , Common Signals


∅1080
