Industrial Fieldbus Slip Rings-(CC-Link/DeviceNet)

Industrial Fieldbus Slip Rings-(CC-Link/DeviceNet)

Product Introduction
JINPAT fieldbus slip rings support a wide range of protocols, including Profibus-DP, CANopen, EtherCAT, Profinet, Modbus, RS485, and Industrial Ethernet. With shielded wiring and isolated channels, they ensure low noise, no packet loss, and stable transmission.
Features:
Various bus types
Low noise, low crosstalk
Wide range of applications
Modular design
Main Applications:
Imaging systems
Wind turbine blade control
Rotating medical scanners
Fieldbus communication between encoders
Lithium battery production lines and precision laser systems
Servo motors and controllers in industrial automation systems

Product Details

Industrial Fieldbus Slip Rings – Reliable Transmission for Modern Automation

JINPAT fieldbus slip rings support a wide range of protocols, including Profibus-DP, CANopen, EtherCAT, Profinet, Modbus, RS485, and Industrial Ethernet. With shielded wiring and isolated channels, they ensure low noise, no packet loss, and stable transmission.


The modular design allows custom combinations of power, signal, encoder, and fieldbus channels—ideal for servo systems, controllers, laser machines, wind turbines, and rotating platforms in harsh industrial environments.


Typical Applications Include:

  • Imaging systems

  • Lithium battery production lines and precision laser systems

  • Wind turbine blade control

  • Rotating medical scanners

  • Fieldbus communication between encoders

  • Servo motors and controllers in industrial automation systems


CC-Link Slip Rings
Typical Model  Circuits Inner Diameter(mm) CC-Link channels Other signal channel Voltage Size（mm） Compatible with both signal types
Special signals Normal signals Outer diameter Length Special signals (U2, U3, SDI, E2, E3、HD-SDI) Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.

LPC-D30-1501-01S

 30 0 1 / / / Φ30 / /
 /

LPC-D39-20S-05E3

 39 0 4 5 0 0~24VAC/DC Φ39 140.5

E3

 /

 TMC-LPC-76A

 0 0 2 3 / 0~240VAC Φ35.5 105.7 E2,E3 /

 LPT400-0730-04S

 7*30A Φ 400mm 1 / / 0~400VAC Φ660 321 / /
Model numbers decode key specs: For example, "LPC-D30-1501-01S-02U3" breaks down as LPC (Capsule type), 30 Circuits, 1 CC-Link bus signal channels, and 2 USB3.0 channels (E4=10G; E2=100M, E3=1G U2=USB2.0 U3=USB3.0).
DeviceNet Slip Rings
Typical Model  Circuits Inner Diameter(mm) CC-Link channels Other signal channel Voltage Size（mm） Compatible with both signal types
Special signals Normal signals Outer diameter Length Special signals (U2, U3, SDI, E2, E3、HD-SDI) Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.

LPT080-0220-05S-01A

 2*20 Φ 80mm 5 / / 240VAC/220AC Φ170 171. /
 /
Model numbers decode key specs: For example, "LPT080-0220-05S" breaks down as LPT (Through-bore type), 80mm inner diameter, 5 DeviceNet bus signal channels.
