- Features:
- Minimum aperture 5mm-6.4mm optional; Customizable high protection, High speed, high life, low torque and other requirements, can be integrated signal
- Main Applications:
- Animal activity recorder
| Electrical & Electronics |
Mechanical |
|||
| Loop number | total | 12CKT |
Working speed | 0~10rpm |
| Details | 12x2A | Contact material | Gold to Gold | |
| Operating voltage | 0~240VAC/DC | Housing ilaterial | Aluminium alloy | |
| Compressive strength | ≥500VAC@50Hz |
Lead Wire Langth |
stator：250±5mm rotor：250 ±5mm |
|
| Insulation resistance | ≥1000MΩ@500VD |
State resistance fluctuation signal |
/ |
|
|
Enviromental |
Others |
|||
| Operating temperature | -20°C~+60°C | Application field | Animal activity recorder |
|
| Working humidity | ≤60%RH |
|||
| Class of protection | IP40 | |||
