The application technology of slip-ring in the cable winch relates to the technology field of submarine pipeline buried equipment,
which is a conductive device that connects and transmits power and monitoring information between the above-water equipment and the underwater equipment.
The umbilical cable of the water-jet buried machine is mostly loaded by coil, which occupies a large area and has many hands when it is collected, and is not suitable for operation on a small ship.
The way to solve this problem is to use the umbilical cable winch, but the use of the winch requires the corresponding umbilical cable slip ring to ensure the
uninterrupted transmission of power and monitoring signals between the mother ship and the underwater buried machine.
For more details about this slip ring product, please contact JINPAT and we will bring you a customized solution to your satisfaction!
| Electrical & Electronics |
Mechanical |
| Circuits |
Total
|
4CKT
|
Rotational speed |
0~1rpm |
| Detail |
3*350A+1*PE |
Contact material |
copper-graphite |
| Operating voltage |
380VAC |
Shell material
|
Q235 |
Dielectric Strength
|
≥1500VAC@50Hz
|
Conductor specification |
95mm soft rubber wire |
| Insulation resistance |
≥1000MΩ@500VDC |
Conductor length |
/ |
| Enviromental |
Others |
| temperature |
-10°C~+60°C |
Life span |
customizable |
| humidness |
≤90%RH
|
Protection Grade
|
IP65 |
