JINPAT Diversified Hollow Shaft Slip Ring Customization Solution

Like other industrial industries, the customization rate of slip ring products is very high in the slip ring industry. As a globally renowned slip ring manufacturer, JINPAT customization rate for products has reached nearly 95%. Among these customized products, hollow shaft slip rings are one of the main products, with various appearances and functional module combinations. These customized versions of hollow shaft slip rings can integrate telecommunication signals, gas-liquid modules, multiple signal channels, power modules, as well as integrated products such as optoelectronics and high-frequency, etc.

Hollow shaft slip rings are a strategic product of JINPAT, which can be divided into two categories: standard and customized. The standard model of JINPAT hollow shaft only transmits current, with four specifications of 2A, 5A, 10A, and 15A. Among them, the product with a 12.7mm aperture is relatively special, with only a 2A product in this series and no 15A model. In addition, products with other standard apertures are all current products of 5A, 10A, and 15A. The products of the standard model are designed based on the development history of the electromechanical industry, so they have good versatility. However, in some cases, the standard model cannot meet the needs of certain equipment, so customization is required.

The JINPAT hollow shaft slip ring provides a wide range of combinations, including options for the shell, main shaft material, and structural design. For example, the recently customized LPT050-0601 hollow shaft slip ring model by JINPAT is a very simple product in terms of its parameters, with only six 1A current paths integrated. However, this product has a very unique design. Firstly, both the shell and main shaft are made of SUS304 stainless steel, which is completely different from JINPAT's other hollow shaft slip rings. The stainless steel color of the slip ring's shell and main shaft, along with the anti-vibration structural design, give this type of slip ring strong anti-vibration and impact resistance capabilities. Additionally, with an IP64 protection level, it can operate stably for a long time in harsh environments.

In addition to these highly personalized customized products, JINPAT is also actively exploring modular integration of hollow shaft slip rings. By using the center through-hole of the hollow shaft slip ring, fiber optic slip rings, high-frequency slip rings with flanges, and capsule slip rings with flanges can be installed, allowing for very flexible combinations and saving a lot of product development time. JINPAT has rich product development experience and strong technical strength in slip ring fields such as engineering machinery, and has the ability to develop special slip rings for various types of special vehicles and machinery, providing products such as multi-signal power integration, gas-liquid electric multi-module integration slip rings to fully meet various needs.
