RF Rotary Joint Integrated Slip Rings

JINPAT RF-Electrical integrated slip rings combine high-frequency rotary transmission with power and signal channels in a compact, high-performance assembly. Supporting frequencies up to 67GHz and various digital signals such as Ethernet and CAN bus, these hybrid solutions are ideal for applications requiring reliable data, RF, and power transmission through a single rotating interface.

With low insertion loss (<0.4dB@18GHz), excellent VSWR (<1.5@18GHz), and multi-layer electromagnetic shielding, JINPAT’s designs ensure stable, low-interference signal integrity even in harsh environments. Featuring precious metal contacts and robust construction, these integrated units have passed stringent temperature and durability tests, making them suitable for aerospace, defense, radar, and high-end industrial systems.

Custom designs are available with over 12 interface options (SMA, N, BNC, etc.) to meet the unique requirements of each application. Whether for UAVs, robotic platforms, or test equipment, JINPAT offers fast, flexible integration solutions tailored to your needs.

Features

◆ Full-Frequency Compatibility

◆ Ultra-Low Signal Loss

◆ Enhanced Anti-Interference

◆Rugged for Military Environments

◆Compact & Lightweight

◆Fast Customization

Application

◆Drones

◆Robotics

Customization & Services

Tailor your slip ring with specific signal types, channel counts, protection levels, or mounting styles. 3D CAD models and technical support are available upon request.

Can’t find a suitable model? Contact us for 24/7 technical support.

For detailed product specifications , refer to product datasheets or contact our sales team.

Optimized for global markets – Precision-engineered for reliability in mission-critical applications.
