LPT-060 Series Through Bore Slip Rings

Product Introduction: JINPAT's LPT-060 Series Through Bore Slip Rings, inner diameter is 60mm, outer diameter is 135mm, 6 channels * 5A, can be combined with power supply, signal, Ethernet, USB, control network, CANBUS, PROFIBUS, can also be installed through the shaft or optional flange installation. It provides an economical, readily available solution when compact through-hole configurations are required. LPT060 Series Through Hole Slip Rings, 15 amps per circuit, available in 4 housing lengths in 6, 12, 18 and 24 ring configurations. Similar in design to our very popular LPT025 series, this design features long life, fiber brush contact technology for ultimate performance in many challenging applications. The fiber brushes require no lubrication and generate almost no wear debris, allowing for maintenance-free, lifetime operation.

Features:: Transmit analog and data signals; Compatible with data bus protocols; Long life;maintenance-free; Easy to install; Multiple points of contact every way; Low contact pressure

Main Applications:: Equipment turret; controlling device; High-speed rail; Drones; Medical Equipment

Product Details

Electronic & Electric			Mechanical
Circuits	Total	6 CKT	Working Speed	0~300rpm
	Detail	5A	Inner Diameter	∅60mm
Rating Voltage		240VAC/DC	Contact Material	Precious Metal
Dielectric Strength		1000VAC@50Hz	Shell Material	Aluminum alloy
Insulation Resistance		≥500MΩ@500VDC	Lead Wire Length	Stator:300mm Rotor:300mm
Environment			Remarks
Working Temperature		-20°C~+60°C	Application	/
Working Humidity		≤60%RH	Other	/
IP		IP54 or higher	Note: "P" stands for power, "S" stands for signal.
