Typical High Frequency Auxiliaries N-F-N-F(75Ω）
Typical High Frequency Auxiliaries N-F-N-F(75Ω）
Typical High Frequency Auxiliaries N-F-N-F(75Ω）

Typical High Frequency Auxiliaries N-F-N-F(75Ω）

Product Introduction
The High Frequency Phase-Stable Low Loss Coaxial Cable Series, along with High Frequency Cable Auxiliaries and High Frequency Test Cable Auxiliaries, are widely used in the aerospace industry, electronic countermeasures systems (ECM), high-frequency anechoic system connections, and 5G mobile communications, among other applications.

Product Details

The High Frequency Phase-Stable Low Loss Coaxial Cable Series, along with High Frequency Cable Auxiliaries and High Frequency Test Cable Auxiliaries, are widely used in the aerospace industry, electronic countermeasures systems (ECM), high-frequency anechoic system connections, and 5G mobile communications, among other applications.


Product specification
Interface Type N-F/NM(75Ω) Body Materials BRASS
Frequency range DC-12GHz Insulator Material PTFE
VSWR,Max 1.3 Durability ＞500cycles
Insertion loss,Max 1.0dB Operation Temperature -30~+75°C
Voltage rating 250V(rms) Storage Temperature -30~+75°C

Dielectric withstanding

voltage

 1000V Humidity(Operation) 95%
Insulation resistance 5000MΩ Humidity(Storage) 95%


N-F-N-F(75Ω）Product Outline Diagram
