Typical High Frequency Auxiliaries BNC-M-BNC-M-RF1.32-500mm

Typical High Frequency Auxiliaries BNC-M-BNC-M-RF1.32-500mm

Product Introduction
The High Frequency Phase-Stable Low Loss Coaxial Cable Series, along with High Frequency Cable Auxiliaries and High Frequency Test Cable Auxiliaries, are widely used in the aerospace industry, electronic countermeasures systems (ECM), high-frequency anechoic system connections, and 5G mobile communications, among other applications.

Product Details

The High Frequency Phase-Stable Low Loss Coaxial Cable Series, along with High Frequency Cable Auxiliaries and High Frequency Test Cable Auxiliaries, are widely used in the aerospace industry, electronic countermeasures systems (ECM), high-frequency anechoic system connections, and 5G mobile communications, among other applications.



Product specification
Interface Type BNC-M/BNC-M(75Ω) Body Materials BRASS/PTFE
Frequency range DC-3GHz Plating GOLD/NICKEL
VSWR,Max 1.5 Durability ＞500cycles
Insertion loss,Max 2.8dB Temperature range ﹣40~+85°C
Voltage rating 170V(rms) RoHS 2002/95/EC RoHS compliant
Dielectric withstanding   voltage 250V Cable retention force ＞2lbs
Insulation resistance 1000MΩ Min.bending radius，repeated 14mm


BNC-M-BNC-M-RF1.32-500mm Typical High Frequency Auxiliaries
